Product Name: Tritan XCMT-08 Multi-Function Rotary Tooling Kit – Complete Drill, Turn & Bore Solution
Product Subtitle: One Tool, Infinite Operations. Master Complex Parts with a Single, Precision Setup.
Main Product Image: Kit case open, showing the tool holder, multiple inserts, wrench, and literature against a clean, industrial background.
Short Description (Above the Fold):
Eliminate tool changes and master complex geometries with the Tritan XCMT-08 Multi-Function Kit. Engineered for CNC and precision lathe work, this versatile system seamlessly transitions between drilling, turning, profiling, and boring using a single holder and our premium XCMT negative rake inserts. Reduce setup time, minimize errors, and unlock new levels of machining efficiency. The complete kit includes everything you need to start machining smarter, not harder.
Key Features & Benefits
TRUE MULTI-FUNCTION DESIGN: One rugged, precision-ground holder performs the work of four separate tools. Perfect for complex parts, prototypes, and small batch production where reducing setup is critical.
PREMIUM XCMT INSERTS (5-PACK): Features versatile negative rake XCMT-08 inserts. Benefits: Exceptional edge strength, excellent chip evacuation (with chipbreaker geometry), and cost-effective indexability. Compatible with a wide range of materials including steel, stainless, cast iron, and non-ferrous metals.
COMPLETE READY-TO-RUN KIT: Includes the tool holder, 5x XCMT-080308 inserts (various grades optional), torque wrench, edge prep pad, and comprehensive setup guide. No need to source parts separately.
OPTIMIZED FOR SPEED & RIGIDITY: The compact, overhung design provides superior rigidity compared to traditional boring bars, allowing for more aggressive cuts and better surface finishes in deep bore or turn applications.
REDUCE TOOLING COSTS & INVENTORY: Dramatically cuts the number of dedicated tools you need to purchase and store. A single insert type covers a vast range of operations.
Detailed Specifications
Holder:
Model: TR-MF08-SDCLNR-50
Shank: ½" (12mm) Solid Carbide Shank (or C5/C6 Steel options)
Function: Drilling, Turning, Profiling, Boring
Max Drilling Depth: 2x Diameter (e.g., 1" deep with a ½" shank)
Insert Seat: Negative Rake, Lever-Lock Clamp System
Coolant Through: Yes (optimized for internal coolant delivery)
Inserts (Included):
Style: XCMT-080308 (8mm cutting edge, 3.175mm hole, 0.8mm corner radius)
Quantity: 5 Pieces
Grade Options: (Select at checkout)
TICN (Titanium Carbo-Nitride): General purpose for steel & stainless.
TIALN (Titanium Aluminum Nitride): For higher temperatures & higher speeds.
Uncoated Carbide: For non-ferrous metals (Aluminum, Brass, Plastics).
Kit Contents:
1x Multi-Function Tool Holder
5x XCMT-080308 Inserts (Grade as selected)
1x Precision Torque Wrench (for consistent clamping)
1x Insert Edge Prep/Honing Pad
1x Quick-Start Setup & Speed/Feed Chart
1x Protective Storage Case
How It Works / Application Guide
Drilling: Center-drill first, then engage the tool to drill to depth. Excellent for creating starter holes or short, precise holes without a dedicated drill.
Turning: Use the side cutting edge for facing, OD turning, and profiling. The robust insert geometry handles interrupted cuts well.
Boring: The short overhang and rigid shank make it ideal for internal boring, achieving fine tolerances and excellent surface finish where long, slender boring bars chatter.
Profiling: Perfect for complex contours, radii, and chamfers on both OD and ID features.
Ideal For:
CNC Machining Centers (Vertical & Horizontal)
CNC Lathes with Live Tooling
Precision Tool Rooms & Prototype Labs
Makers & Advanced Hobbyists with capable equipment
